GreenSolarShade

Development of a metallic structure shading system that integrates green roofs, recovery of rainwater and the production of photovoltaic energy

  • Project code
    POCI-01-0247-FEDER-017844
  • Approval date
    07/12/2016
  • Start date
    01/09/2016
  • Conclusion date
    31/08/2018
  • Promotor
    Constálica
  • Copromotors
    Itecons ANQIP
  • Intervention region
    Região Centro
  • Total eligible amount
    573.878,46 €
  • Financial support from the European Union
    FEDER - 370.015,85 €
  • Funding

INTRODUCTION

This project focuses on the development of an innovative and sustainable green roof shading structure for car parks with energy production and rainwater harvesting features. The solution is a hybrid system that integrates green roof modules, PV panels with sun tracking and a rainwater harvesting. The project, with 24 months duration, started in September 2016 and involved Constálica (lead promotor), Itecons and ANQIP (R&D entities).



MAIN GOALS

  • Theoretical characterization of the solution in terms of water and energy behaviour, as well as in terms of mechanical and environmental performance;
  • Definition of a modular manufacturing process for the metal structure and the solar tracking mechanism, looking to reduce manufacturing and transport costs and ensure the competitiveness of the solution, both in national and international markets;
  • Prototype construction and its characterization in laboratory and in-situ environment;
  • Definition of guidelines and rules for implementing the solution;
  • Production of technical and scientific documentation with information on the solution and with dissemination of the project’s results.



PROJECT ACTIVITIES AND EXPECTED RESULTS

The main activities set out to be carried out during the project are:

  • The carrying out of preliminary studies consisting in market analysis and definition of requirements to be met by the solution;
  • The development and specification of each component of the innovative system;
  • The industrial development of the system;
  • The carrying out of an experimental validation campaign;
  • The dissemination and promotion of the project’s results.



MAIN RESULTS ACHIEVED

Preliminary studies and system design: The target market with the greatest potential for acceptance of the solution was identified and the demands and requirements to be met by the system were defined.

Solution development and specification: A one axis system with a horizontal axis (N-S) was defined (enabling E-W sun tracking between -30° and 30°). A tracking control algorithm based on astronomical equations was implemented, allowing the maximization of solar radiation collection and taking into account the action of the wind. All control, energy generation and storage, and security components were specified.

Efficiency improvement with solar tracking: In comparison with a fixed inclination solution, a 9% energy production increase was estimated A 25% increase was estimated in comparison with a horizontal panels solution.

Life Cycle Analysis (LCA): A comparative assessment concluded that the system leads to a significant reduction in environmental impacts (55 to 77% when compared to a conventional shading system and 5 to 21% when compared to a fixed system) in most environmental categories due to the production of solar energy in the use stage.

Increased biodiversity: It was found that the use of a mixture of herbaceous vegetation with sedum and grasses is suitable for exposure in full sun and half shade (panel area) and that it offers a wide variety of species.

Reduction of rainwater runoff: For the modular green roof solution, a percentage of water retention between 20% and 40% was obtained.

Filtering rainwater: Drainage tests were performed using pollutants typically found in pavements. It revealed a high capacity for retaining heavy metals (between 70 and 96%) as well as oils and fats (approximately 30%).

Lightweight and modular solution: For the roof module, a tray measuring 500 mm x 500 mm was selected. This corresponds to a modular solution weighing between 14 kg and 17.5 kg, which allows for easy handling and assembly.

Increased sound absorption coefficient: A weighted sound absorption coefficient (αW) greater than 0.75 was obtained from an experimental campaign carried out in a reverberant chamber.

Reduction of heat flux to the environment: The influence of the green roof on the surrounding temperature and energy production of the PV panels was evaluated.
